Land Telegraph
Keys, Sounders, Etc.




Hughes Telegraph
Dumoulin - Froment a Paris
Mid 19th Century

Operated on the Paris - Milan line





Breguet Dial (ABC) Telegraph Transmitter
(French)
1850 -1870


Breguet Dial (ABC) Telegraph Receiver
(French)
1850 - 1870




Telegraphy Statue


Unknown Telegraph Key


English
Telegraph Key


Toy ABC Telegraph
4th Qtr 19th Century


Bunnell Telegraph Relay
1895


Western Electric 7A 1K Ohm Telegraph Sounder
c. 1900 - 1920


Bunnell "Barclay Relay"
(not sure of the date - Telegraph isn't my specialty!)


Radiguet & Massiot
Telegraph Receiver





Bonderi Needle Telegraph Receiver
(Italy)

2nd Half 19th Century

Each letter of the alphabet is printed around the top edge, and has a corresponding coil of wire.  A character is sent by passing a current through the corresponding coil, creating a magnetic field which turns the needle to indicate which character is being sent.

This device is one of a generation of telegraph devices invented before the development of Morse code.  The response of the needle is very slow and each alphabetic character requires a separate wire between the transmitter and receiver, or 26 wires in all.  "Needles" to say, (sorry) these early telegraphs were not very practical and saw little commercial use.
